Mavic Wheels | Crossmax 29" Boost Set

MTB Wheels - Crossmax 29"
Featuring Infinity hubs, ID360 freewheel, and Maxtal welded rims, this modern XC wheel lives up to the legendary Crossmax name: strong, reliable, and tubeless-ready.

The name Crossmax has a long history in the world of XC riding and racing and this new wheelset live up to its name with many of the same features and technologies as pro-level XC race wheels but at a far more attainable price. One of the key factors in our UST technology, which allows for easy setup of tubeless-ready tires and gives you all the associated benefits including better traction and control, smoother ride quality, and a reduced risk of punctures. The rim is welded for added reliability and features a 25mm internal width with a hookless profile.

The Infinity lighter hub design optimizes lateral stiffness and spokes tension. Our Instant Drive 360 freewheel with a double ratchet system provides fast engagement and top-level reliability. The rear hub is compatible with Shimano HG9, Micro Spline, and SRAM XD driver bodies. The Crossmax is available with 6-bolt or center lock brake rotors in 29” and 27" and is compatible with a 15x110 front axle and 12x148 rear. The wheel is delivered with valves, replacement spokes, and accessories.

• Weight: 1770 grams (Pair 29")
• Weight: 820 grams (Front 29")
• Weight: 950 grams (Rear 29").

Key Benefits

Light and durable
Welded rim construction for a light and strong rim profile and a perfectly sealed rim

Dynamic and agile
24 double-butted spokes Infinity hub platform ID360 double ratchet freewheel​ system

Tubeless-ready technology
A tubeless rim profile and tubeless tape make it easy to ride tubeless tires for more comfort and control

Specifications

Rims

• Material: Maxtal
• Drilling: traditional
• Valve hole diameter: 6.5 mm
• Internal width: 25 mm
• ETRTO size 29": 622x25TSS
• Use with Mavic Tubeless Tape
• Asymmetrical rim design
• UST Tubeless Ready
• SUP

Spokes

• Material: steel
• Shape: straight pull, flat, double-butted
• Nipples: steel, ABS
• Count: 24 front and rear
• Lacing: front and rear crossed 2

Hubs

• Axles: Front 15X110 (Boost) or 15x100 ; Rear 12X148 (Boost) or 12x142
• Hub available with 6-bolt or center lock (R) brake rotors
• Infinity Hub
• Instant Drive 360
• QRM Auto
• Versions
• Disc standard: 6 Bolts or Center Lock (R)
• Hub width : Boost (front 110, rear 148) or Non-Boost (front 100, rear 135/142)
• Freewheel: SRAM XD, Shimano HG9, Shimano Micro-Spline

Compatibility

• Front axle: convertible from 15mm thru-axle to Quick Release with adapters (delivered with non-boost wheel)
• Rear-axle: 12mm thru-axle, convertible to Quick Release with adapters (delivered with non-boost wheel)
• Compatible Adapters and freewheel bodies
• Non-Boost : 15 to 9mm front adapter for quick release (L99694100)
• Boost : Torque Caps (LV2374400)
• 12x142 rear axle adapters ([LV2510700]l)
• Non-Boost: 12 to 9mm rear adapter for quick release (LV2510801)
• Non-Boost : 12x135 rear axle adapters (LV2510900)

Intended use

• ASTM CATEGORY 3: CROSS COUNTRY
• For a longer longevity of the wheel, Mavic recommends that the total weight supported by the wheels doesn't exceed 150kg, bike included
• Recommended tyre sizes: 50mm to 76mm (2.0" to 3.0")

Delivered with

• UST valve and accessories
• Pre-installed tubeless rim tape
• 2 replacement spokes with each wheel.
