Praxis Cranksets | Alba M30 Direct Mount

The Alba M30 road crank uses the M30 spindle/BB system. Our M30 BBs are made for Eng Threaded, BB86, BB30, PF30, and Specialized OSBB road frames.

Shimano - Our rings work great with both mechanical Shimano 10/11sp drivetrains and also their Di2 Electronic drivetrains. We do highly suggest using a Shimano, KMC, or Campy chain.

Sram - Our rings work great with the SRAM 10sp and “SRAM 22″ 11sp chain drivetrains. The crank and rings also work well with the SRAM “Yaw” front derailleur. We do highly suggest using a Shimano, KMC, or Campy chain.

Campy - Our rings work great with both mechanical Campagnolo 10/11sp drivetrains and also their EPS Electronic drivetrains. We do highly suggest using a Shimano, KMC, or Campy chain.

Specifications

• Solid forged arms – 110BCD
• 2X – 48/32, 50/34
• 170mm arm length
• M30 AL Spindle – 30mm with 28mm step-down
• Requires Praxis M30 BB: BSA, BB86, 386EVO, BB30/PF30 (30mm Drive/28mm NonDrive)
• Works with Shimano™ 10/11, Campy 10/11, SRAM 10/11
• Weight 775g +/- (172.5 with 50/34)
• Q-Factor 147mm

Technology

• Forged crank arms
• Praxis Cold Forged rings with LevaTime® shifting tech
• M30 Spindle/Bottom Bracket System.

SKU# PXS-DM-A160-5034
